ESKIMOS, an aluminum system designed for those with discerning taste, offers classic design coupled with standard technical parameters and coefficients. Ideal for xed, uniaxial, and biaxial opening mechanisms, ESKIMOS combines timeless aesthetics with reliable performance for a touch of sophistication in any space.
| Maximum dimensions | |
|---|---|
| Min. sash height | 280 mm |
| Max. sash height | 2400 mm |
| Min. sash width | 200 mm |
| Max. sash width | 1600 mm |
| Visible parts of profiles | |
|---|---|
| Min. frame width | 53 mm |
| Min. frame height | 59 mm |
| Min. sash width | 61 mm |
| Min. height of frame with sash | 81 mm |
| Double glazing | |
|---|---|
| Height of the rabbet | 22 mm |
| Min. width of glazing | 20 mm |
| Max. width of glazing unit | 38 mm |
| Characteristics | |
|---|---|
| UW | 1.2 W/m2K |
| Max. sash weight | 80 kg |
7015
1013
1015
5010
5023
5024
6003
6005
6009
6021
7005
7006
9010
7016
7022
7024
7030
7035
7037
7038
7040
8014
9005
9006
9007
1019
5010
6009
7012
7016
7030
7039
7042
8017
9016
Golden Oak
Light Oak
Nussbaum
Pear Tree
Pine
Red Cherry
Walnut
Wenge
